ETX- 500 HORIZONTAL CLOSED END BALER

FEATURES/BENEFITS

• Produces proper dimensional mill size bales 1100 x 750mm
• Complete bale injection
• Multiple loading options
• Fully EU Health & Safety compliant
• Easy to operate – requires minimal servicing

SPECIFICATIONS AND DIMENSIONS

Baler Dimensions L X W x H	5695mm x 1385mm x 2190mm
Baler Weight Tonnes	5 Tonnes
Bale Size W x H	750mm x 1100mm
Bale Length	Variable
Bale Weight	450-650 Kgs depending on material
No of Bale Ties	4 Wire or Tape
Loading Aperture	1250mm x 750mm
Safety Circuits	Dual Channel Cat 4
Control Voltage	24 Volt
Switch Gear	PLC Controlled
Motor Size	11 Kw
Cylinder Bore	152mm
Compaction Force @ 200 bar*	38 Ton
Cutting Face on Baler Cross Bar	Serrated V Shape Blades
Cutting Face on Packing Blade	Anvil Shear Blades
End Door Type	Manual
Full Bale Eject of Each Individual Bale	Included
Cycle Time	74 Secs (Std) : 48 Secs (Optional)
CE Compliant	Yes

ET – LHV300 SINGLE CHAMBER VERTICAL BALE

FEATURES/BENEFITS

• Low height baler perfect for limited spaces
• Easy to transport and install
• Automatic compaction cycle with bale full light
• Fully automated bale ejector makes ejection clean and simple
• Tie off bale with doors open
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	1990 mm
Width	1800 mm
Depth	1100 mm
Weight	1140 Kgs
Power Supply	Single Phase 220-240V
Motor	2.2 KW 16 amp
Pressing Force	Up to 20 Tonnes
Noise Level	68 Decibels
Cycle Time	45 Seconds

LOADING APERTURE SIZES

Height	600 mm
Width	1200 mm
Depth	800 mm

BALE DIMENSIONS

Height	1000 mm
Width	1200 mm
Depth	800 mm
Weight	Up to 300 Kgs (Depending on material)

ET – V60 SINGLE CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Produces a bale that can be manually handled and easy to store
• Ideal for small to medium waste volumes
• Automatic compaction cycle with bale full light
• A compact baler with easy loading, taking up minimal space
• Comes with bale lifting trolley
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	2300 mm
Width	1040 mm
Depth	720 mm
Weight	270 Kgs
Transportation Ht	1800 mm
Power Supply	Single Phase 240v
Motor	1.5 KW 13 amp
Pressing Force	Up to 4 Tonnes
Noise Level	72 Decibels

LOADING APERTURE SIZES

Height	698 mm
Width	700 mm
Depth	500 mm

BALE DIMENSIONS

Height	600 mm
Width	700 mm
Depth	500 mm
Weight	Up to 75 Kgs
Cycle time	24 seconds

ET – V63 MILL SIZE VERTICAL BALER

FEATURES/BENEFITS

• Full Safety electrical interlocks on doors
• Auto Loading door opening on return ram cycle
• Key operated controls
• Low 24-volt operator control panel
• Fully Auto press ram cycle
• Dual control bale eject system
• Bale full indicator
• Material retention claws
• Bale wire guidance system
• Lifetime structural warranty
• CE Compliant

OPTIONS

• High speed cycle (regenerative hydraulics)
• Customer Signage

TECHNICAL SPECIFICATION

Motor	11 kW
Platen Force	50t
Cycle Time	32 sec
Electrical	415, 3-PHASE
Overall (W x D x H)	2030 x 1092 x 3620 mm
Feed Height	1232 mm
Loading Aperture	1524 x 705 mm
Bale (W x D x H)	1524 x 762 x 1220 mm
Bale Weight (OCC)	Up to 550 kg
Ejector System	Semi Automatic
Baler Weight	2045 kg

ET – V75 MULTI CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Produces a bale that can be manually handled and easy to store
• Multi chambers allow you to separate and recycle different materials
• Roller guided head for ease of movement
• Saves handling time as you’re free to load one chamber whilst the other compacts
• Retaining claws to prevent material spring back
• Up to six additional chambers can be added
• Comes with bale lifting trolley
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	1969 mm
Width	2050 mm
Depth	872 mm
Weight	562 Kgs
Transportation Ht	1969 mm
Power Supply	Single Phase 240v
Motor	1.3 KW 13 amp
Pressing Force	Up to 4 Tonnes
Noise Level	72 Decibels

LOADING APERTURE SIZES

Width	700 mm
Depth	500 mm

BALE DIMENSIONS

Height	1000 mm
Width	700 mm
Depth	500 mm
Weight	Up to 75 Kgs
Cycle time	35 seconds

ET – V75 SINGLE CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Produces a bale that can be manually handled and easy to store
• Ideal for small to medium waste volumes
• Press ram can stop in down position, ideal for materials with memory such as LDPE plastics
• A compact baler with easy loading, taking up minimal space
• Comes with bale lifting trolley
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	2300 mm
Width	1040 mm
Depth	720 mm
Weight	270 Kgs
Transportation Ht	1800 mm
Power Supply	Single Phase 240v
Motor	1.5 KW 13 amp
Pressing Force	Up to 4 Tonnes
Noise Level	72 Decibels

LOADING APERTURE SIZES

Height	698 mm
Width	700 mm
Depth	500 mm

BALE DIMENSIONS

Height	1000 mm
Width	700 mm
Depth	500 mm
Weight	Up to 75 Kgs
Cycle time	24 seconds

ET – V150 SINGLE CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Bale weight output of up to 150 Kgs
• A mid range baler with easy loading for large size boxes and material
• Press ram can stop in down position, ideal for materials with memory such as LDPE plastics
• Fully automated bale ejector makes ejection clean and simple
• Retaining claws to prevent material spring back
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	2600 mm
Width	1560 mm
Depth	1030 mm
Weight	780 Kgs
Power Supply	Single Phase 240v
Motor	2.2 Kw
Pressing Force	Up to 10 Tonnes
Noise Level	72 Decibels

LOADING APERTURE SIZES

Height	470 mm
Width	975 mm

BALE DIMENSIONS

Height	1000 mm
Width	975 mm
Depth	800 mm
Weight	Up to 150 Kgs
Cycle time	40 seconds

ET – V200 MULTI CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Produces a Euro pallet size bale
• Multi chambers will allow you to separate and recycle different materials
• Roller guided head for ease of movement
• Saves handling time as you’re free to load one chamber whilst the other compacts
• Retaining claws to prevent material spring back
• Up to six additional chambers can be added
• Fully automated bale ejector simplifies the removal of the bale
• A simple, easy to use system
• CE Compliant

BALER DIMENSIONS

Height	2469 mm
Width	3032 mm
Depth	1269 mm
Weight	1400 Kgs
Transportation Ht	2469 mm
Power Supply	Single Phase 240v
Motor	2.2 KW 16 amp
Pressing Force	Up to 22 Ton
Noise Level	74 Decibels

LOADING APERTURE SIZES

Width	1074 mm
Depth	800 mm

BALE DIMENSIONS

Height	1000 mm
Width	1074 mm
Depth	800 mm
Weight	Up to 250 Kgs
Cycle time	34 seconds

ET – V250 SINGLE CHAMBER VERTICAL BALER

FEATURES/BENEFITS

• Produces a Euro pallet size bale
• A mid range baler with easy loading for large size boxes and material
• Press ram can stop in down position ideal for materials with memory such as LDPE plastics
• Fully automated bale ejector makes ejection clean and simple
• Retaining claws to prevent material spring back
• A simple easy to use system
• CE Compliant

BALER DIMENSIONS

Height	2990 mm
Width	1500 mm
Depth	980 mm
Weight	985 Kgs
Transportation Ht	2250 mm
Power Supply	Single Phase 240v
Motor	2.2 KW 16 amp
Pressing Force	Up to 20 Tonnes
Noise Level	74 Decibels

LOADING APERTURE SIZES

Height	678 mm
Width	1200 mm
Depth	800 mm

BALE DIMENSIONS

Height	1000 mm
Width	1200 mm
Depth	800 mm
Weight	Up to 250 Kgs
Cycle time	34 seconds

ET – 1100 BIN PRESS

FEATURES/BENEFITS

• Reduces frequency of daily/weekly bin collections
• A compaction ratio of up to 4:1 (depending on material)
• Base lifting plate ensures bin wheels are not damaged during compaction
• A two handed operation makes for a safer working environment
• Adaptor available to compact 660 ltr bins
• A simple, easy to use system
• CE Compliant

DIMENSIONS

Height	2120 mm
Width	1160 mm
Depth	1150 mm
Weight	270 Kgs
Transportation Ht	1650 mm
Power Supply	Single Phase 240v
Motor	1.5KW 13 amp
Pressing Force	Up to 4 Tonnes
Noise Level	72 Decibels
Cycle time	20 seconds

ET-ROLL-ON PORTABLE COMPACTOR

FEATURES/BENEFITS

• Fully contained – 100% leak proof
• Full safety interlocks
• ¾ full and full warning lights guaranteeing maximum container payloads
• Cleanline and conical container design for easy emptying
• Lockable vandal proof control covers
• Multi cycle timer
• CE Compliant

OPTIONS

• Customized tippers & Hoppers
• Universal mobile or integrated bin tippers
• Remote control station via cable and plug
• Drainage valve to rid excess fluid
• Swept ram option for wet waste applications
• Rear position hook lift
• Colour choice & customer signage

Model Type	ET-16ST	ET-18ST	ET-20ST	ET-22ST	ET-24ST
Motor	5.5kW	5.5kW	5.5kW	5.5kW	5.5kW
Supply 3ø50~415V	16A	16A	16A	16A	16A
Compaction Force	34t	34t	34t	34t	34t
Cycle Time	52 sec	52 sec	52 sec	52 sec	52 sec
Capacity	16m3	18m3	20m3	22m3	24m3
Volume/stroke	1.31m3	1.31m3	1.31m3	1.31m3	1.31m3
Volume/hr	98m3	98m3	98m3	98m3	98m3
Length	5320mm	5520mm	5920mm	6400mm	6800mm
Length c/w tipper	7480mm	7680mm	8080mm	8560mm	8960mm
Width	2470mm	2470mm	2470mm	2470mm	2470mm
Height	2670mm	2670mm	2670mm	2670mm	2670mm
Filling Opening (L x W)	2000 x 1800mm	2000 x 1800mm	2000 x 1800mm	2000 x 1800mm	2000 x 1800mm
Filling Height	1130mm	1130mm	1130mm	1130mm	1130mm

ET – SKIP TYPE PORTABLE COMPACTOR

FEATURES/BENEFITS

• Fully contained – 100% leak proof
• Full safety interlocks
• ¾ full and full warning lights guaranteeing maximum container payloads
• Smooth cleanline and conical container design for easy emptying
• Lockable vandal proof control covers
• Multi cycle timer
• CE Compliant

OPTIONS

• Customized tippers & Hoppers
• Universal mobile or integrated bin tippers 120 - 1100 ltr
• Remote control station via cable and plug
• Drainage valve to rid excess fluid
• Colour choice & customer signage

TECHNICAL SPECIFICATION

Motor	5.5 kW
Power Supply	415V 3ø50~16A
Compaction Force	34t
Cycle Time	35 sec
Capacity	8-12m3
Filling Opening (L x W)	900 x 1510 mm
Filling Height	1230 mm
Volume /stroke	1m3
Volume/hr	100m3
Total (L x W x H)	4.2 x 1.9 x 2.1m

ET-STATIC TYPE COMPACTORS

FEATURES/BENEFITS

• Full safety interlocks
• ¾ full and full warning lights guaranteeing maximum container payloads
• Choice of open splayed or enclosed hopper
• Lockable vandal proof control covers
• Automatic pin off
• Oil & Temperature warning control
• Multi cycle timer
• CE Compliant

OPTIONS

• Customized tippers & Hoppers
• Universal mobile or integrated bin tippers with fully enclosed and interlocked safety cage
• Remote control station via cable and plug
• Synchronised pre-crushing system for difficult waste.
• Auto start photocell sensor
• Colour choice & customer signage

Type	ET-15S	ET-15	ET-20	ET-25	ET-30
Motor	7.5kW	7.5kW	11kW	11kW	11kW
Supply 3ø50~415V	32A	32A	32A	32A	32A
Compaction Force	34t	34t	38t	38t	38t
Cycle Time	39 sec	40 sec	50 sec	55 sec	60 sec
Volume/hr	103m3	96m3	140m3	180m3	240m3
Length	1828mm	3035mm	3724mm	4413mm	5102mm
Width	1753mm	1753mm	1753mm	1753mm	1753mm
Width inc S/M P/Pack	2007mm	2007mm	2007mm	2007mm	2007mm
Height ex Hopper	1220mm	1220mm	1220mm	1220mm	1220mm
Filling Opening (L x W)	1066 x 1524mm	1029 x 1524mm	1372 x 1524mm	1715 x 1524mm	2040 x 1524mm
Filling Height	1220mm	1220mm	1220mm	1220mm	1220mm

ET-STATIC TYPE COMPACTORS WITH SLIDING DOOR

FEATURES/BENEFITS

• Full safety interlocks
• ¾ full and full warning lights guaranteeing maximum container payloads
• Choice of open splayed or enclosed hopper
• Lockable vandal proof control covers
• Automatic pin off
• Oil & Temperature warning control
• Multi cycle timer
• CE Compliant

OPTIONS

• Customized tippers & Hoppers
• Universal mobile or integrated bin tippers with fully enclosed and interlocked safety cage
• Remote control station via cable and plug
• Synchronised pre-crushing system for difficult waste.
• Auto start photocell sensor
• Colour choice & customer signage

Type	ET-15S	ET-15	ET-20	ET-25	ET-30
Motor	7.5kW	7.5kW	11kW	11kW	11kW
Supply 3ø50~415V	32A	32A	32A	32A	32A
Compaction Force	34t	34t	38t	38t	38t
Cycle Time	39 sec	40 sec	50 sec	55 sec	60 sec
Volume/hr	103m3	96m3	140m3	180m3	240m3
Length	1828mm	3035mm	724mm	4413mm	5102mm
Width	1753mm	1753mm	1753mm	1753mm	1753mm
Width inc S/M P/Pack	2007mm	2007mm	2007mm	2007mm	2007mm
Height excl. Hopper	1220mm	1220mm	1220mm	1220mm	1220mm
Filling Opening (L x W	1066 x 1524mm	1029 x 1524mm	1372 x 1524mm	1715 x 1524mm	2040 x 1524mm
Filling Height	1220mm	1220mm	1220mm	1220mm	1220mm
