We have over 20 years of experience in the waste and facilities sector. Our experience allows us to tailor a full FM package to our customers, taking the hassle out of looking for reliable service providers.
We offer a national service through our network of like-minded suppliers. Our main aim is to deliver an excellent service while focusing on your environmental impact.
Evolve Waste Management understands the importance of good customer service. We have several partners across the UK, allowing us to make the right choice to meet your company’s needs.
If you need collections at a specific time of day, NOT A PROBLEM! One of our partners will be able to accommodate your needs, just tell us your requirement and we’ll do the rest.
Our facilities management offering takes the hassle out of looking for a reliable service provider. Visit the ‘Services’ section of our website to see which services we can provide you with. If you can’t find the service you’re looking for, don’t worry, just ask and we’ll be more than happy to find you a provider from our wide range of suppliers.
Why not give us a call on 0333 242 2282 and a member of our team will arrange a site visit.
If you would like to learn more about who we are and what we do, please read our Services Booklet for more information.
Baler Dimensions L X W x H | 5695mm x 1385mm x 2190mm |
Baler Weight Tonnes | 5 Tonnes |
Bale Size W x H | 750mm x 1100mm |
Bale Length | Variable |
Bale Weight | 450-650 Kgs depending on material |
No of Bale Ties | 4 Wire or Tape |
Loading Aperture | 1250mm x 750mm |
Safety Circuits | Dual Channel Cat 4 |
Control Voltage | 24 Volt |
Switch Gear | PLC Controlled |
Motor Size | 11 Kw |
Cylinder Bore | 152mm |
Compaction Force @ 200 bar* | 38 Ton |
Cutting Face on Baler Cross Bar | Serrated V Shape Blades |
Cutting Face on Packing Blade | Anvil Shear Blades |
End Door Type | Manual |
Full Bale Eject of Each Individual Bale | Included |
Cycle Time | 74 Secs (Std) : 48 Secs (Optional) |
CE Compliant | Yes |
Height | 1990 mm |
Width | 1800 mm |
Depth | 1100 mm |
Weight | 1140 Kgs |
Power Supply | Single Phase 220-240V |
Motor | 2.2 KW 16 amp |
Pressing Force | Up to 20 Tonnes |
Noise Level | 68 Decibels |
Cycle Time | 45 Seconds |
Height | 600 mm |
Width | 1200 mm |
Depth | 800 mm |
Height | 1000 mm |
Width | 1200 mm |
Depth | 800 mm |
Weight | Up to 300 Kgs (Depending on material) |
Height | 2300 mm |
Width | 1040 mm |
Depth | 720 mm |
Weight | 270 Kgs |
Transportation Ht | 1800 mm |
Power Supply | Single Phase 240v |
Motor | 1.5 KW 13 amp |
Pressing Force | Up to 4 Tonnes |
Noise Level | 72 Decibels |
Height | 698 mm |
Width | 700 mm |
Depth | 500 mm |
Height | 600 mm |
Width | 700 mm |
Depth | 500 mm |
Weight | Up to 75 Kgs |
Cycle time | 24 seconds |
Motor | 11 kW |
Platen Force | 50t |
Cycle Time | 32 sec |
Electrical | 415, 3-PHASE |
Overall (W x D x H) | 2030 x 1092 x 3620 mm |
Feed Height | 1232 mm |
Loading Aperture | 1524 x 705 mm |
Bale (W x D x H) | 1524 x 762 x 1220 mm |
Bale Weight (OCC) | Up to 550 kg |
Ejector System | Semi Automatic |
Baler Weight | 2045 kg |
Height | 1969 mm |
Width | 2050 mm |
Depth | 872 mm |
Weight | 562 Kgs |
Transportation Ht | 1969 mm |
Power Supply | Single Phase 240v |
Motor | 1.3 KW 13 amp |
Pressing Force | Up to 4 Tonnes |
Noise Level | 72 Decibels |
Width | 700 mm |
Depth | 500 mm |
Height | 1000 mm |
Width | 700 mm |
Depth | 500 mm |
Weight | Up to 75 Kgs |
Cycle time | 35 seconds |
Height | 2300 mm |
Width | 1040 mm |
Depth | 720 mm |
Weight | 270 Kgs |
Transportation Ht | 1800 mm |
Power Supply | Single Phase 240v |
Motor | 1.5 KW 13 amp |
Pressing Force | Up to 4 Tonnes |
Noise Level | 72 Decibels |
Height | 698 mm |
Width | 700 mm |
Depth | 500 mm |
Height | 1000 mm |
Width | 700 mm |
Depth | 500 mm |
Weight | Up to 75 Kgs |
Cycle time | 24 seconds |
Height | 2600 mm |
Width | 1560 mm |
Depth | 1030 mm |
Weight | 780 Kgs |
Power Supply | Single Phase 240v |
Motor | 2.2 Kw |
Pressing Force | Up to 10 Tonnes |
Noise Level | 72 Decibels |
Height | 470 mm |
Width | 975 mm |
Height | 1000 mm |
Width | 975 mm |
Depth | 800 mm |
Weight | Up to 150 Kgs |
Cycle time | 40 seconds |
Height | 2469 mm |
Width | 3032 mm |
Depth | 1269 mm |
Weight | 1400 Kgs |
Transportation Ht | 2469 mm |
Power Supply | Single Phase 240v |
Motor | 2.2 KW 16 amp |
Pressing Force | Up to 22 Ton |
Noise Level | 74 Decibels |
Width | 1074 mm |
Depth | 800 mm |
Height | 1000 mm |
Width | 1074 mm |
Depth | 800 mm |
Weight | Up to 250 Kgs |
Cycle time | 34 seconds |
Height | 2990 mm |
Width | 1500 mm |
Depth | 980 mm |
Weight | 985 Kgs |
Transportation Ht | 2250 mm |
Power Supply | Single Phase 240v |
Motor | 2.2 KW 16 amp |
Pressing Force | Up to 20 Tonnes |
Noise Level | 74 Decibels |
Height | 678 mm |
Width | 1200 mm |
Depth | 800 mm |
Height | 1000 mm |
Width | 1200 mm |
Depth | 800 mm |
Weight | Up to 250 Kgs |
Cycle time | 34 seconds |
Height | 2120 mm |
Width | 1160 mm |
Depth | 1150 mm |
Weight | 270 Kgs |
Transportation Ht | 1650 mm |
Power Supply | Single Phase 240v |
Motor | 1.5KW 13 amp |
Pressing Force | Up to 4 Tonnes |
Noise Level | 72 Decibels |
Cycle time | 20 seconds |
Model Type | ET-16ST | ET-18ST | ET-20ST | ET-22ST | ET-24ST |
---|---|---|---|---|---|
Motor | 5.5kW | 5.5kW | 5.5kW | 5.5kW | 5.5kW |
Supply 3ø50~415V | 16A | 16A | 16A | 16A | 16A |
Compaction Force | 34t | 34t | 34t | 34t | 34t |
Cycle Time | 52 sec | 52 sec | 52 sec | 52 sec | 52 sec |
Capacity | 16m3 | 18m3 | 20m3 | 22m3 | 24m3 |
Volume/stroke | 1.31m3 | 1.31m3 | 1.31m3 | 1.31m3 | 1.31m3 |
Volume/hr | 98m3 | 98m3 | 98m3 | 98m3 | 98m3 |
Length | 5320mm | 5520mm | 5920mm | 6400mm | 6800mm |
Length c/w tipper | 7480mm | 7680mm | 8080mm | 8560mm | 8960mm |
Width | 2470mm | 2470mm | 2470mm | 2470mm | 2470mm |
Height | 2670mm | 2670mm | 2670mm | 2670mm | 2670mm |
Filling Opening (L x W) | 2000 x 1800mm | 2000 x 1800mm | 2000 x 1800mm | 2000 x 1800mm | 2000 x 1800mm |
Filling Height | 1130mm | 1130mm | 1130mm | 1130mm | 1130mm |
Motor | 5.5 kW |
Power Supply | 415V 3ø50~16A |
Compaction Force | 34t |
Cycle Time | 35 sec |
Capacity | 8-12m3 |
Filling Opening (L x W) | 900 x 1510 mm |
Filling Height | 1230 mm |
Volume /stroke | 1m3 |
Volume/hr | 100m3 |
Total (L x W x H) | 4.2 x 1.9 x 2.1m |
Type | ET-15S | ET-15 | ET-20 | ET-25 | ET-30 |
---|---|---|---|---|---|
Motor | 7.5kW | 7.5kW | 11kW | 11kW | 11kW |
Supply 3ø50~415V | 32A | 32A | 32A | 32A | 32A |
Compaction Force | 34t | 34t | 38t | 38t | 38t |
Cycle Time | 39 sec | 40 sec | 50 sec | 55 sec | 60 sec |
Volume/hr | 103m3 | 96m3 | 140m3 | 180m3 | 240m3 |
Length | 1828mm | 3035mm | 3724mm | 4413mm | 5102mm |
Width | 1753mm | 1753mm | 1753mm | 1753mm | 1753mm |
Width inc S/M P/Pack | 2007mm | 2007mm | 2007mm | 2007mm | 2007mm |
Height ex Hopper | 1220mm | 1220mm | 1220mm | 1220mm | 1220mm |
Filling Opening (L x W) | 1066 x 1524mm | 1029 x 1524mm | 1372 x 1524mm | 1715 x 1524mm | 2040 x 1524mm |
Filling Height | 1220mm | 1220mm | 1220mm | 1220mm | 1220mm |
Type | ET-15S | ET-15 | ET-20 | ET-25 | ET-30 |
---|---|---|---|---|---|
Motor | 7.5kW | 7.5kW | 11kW | 11kW | 11kW |
Supply 3ø50~415V | 32A | 32A | 32A | 32A | 32A |
Compaction Force | 34t | 34t | 38t | 38t | 38t |
Cycle Time | 39 sec | 40 sec | 50 sec | 55 sec | 60 sec |
Volume/hr | 103m3 | 96m3 | 140m3 | 180m3 | 240m3 |
Length | 1828mm | 3035mm | 724mm | 4413mm | 5102mm |
Width | 1753mm | 1753mm | 1753mm | 1753mm | 1753mm |
Width inc S/M P/Pack | 2007mm | 2007mm | 2007mm | 2007mm | 2007mm |
Height excl. Hopper | 1220mm | 1220mm | 1220mm | 1220mm | 1220mm |
Filling Opening (L x W | 1066 x 1524mm | 1029 x 1524mm | 1372 x 1524mm | 1715 x 1524mm | 2040 x 1524mm |
Filling Height | 1220mm | 1220mm | 1220mm | 1220mm | 1220mm |
